NO. | Property | Description |
1 | Brand/Origin Place | Safebuild/Shandong China |
2 | Product Name | Radius/Curved Beam Highway Guardrail |
3 | Material | Steel Grade Q235,Q345,S235JR,S275JR,S355JR,EN10025,A283M. |
4 | Surface treatment | Hot dipped galvanized or powder coating |
5 | Zinc coating | 300g/㎡ (40um), 550g/㎡ (80um),610g/㎡ (85um),1100 g/㎡ (160um),1220 g/㎡ (170um) or customized |
6 | Thickness | 2.5/2.75/3.0mm or customized |
7 | Standard Size | Customized |
8 | Certificate | AASHTO/AS/NZS/EN1317/ISO9001/ISO14000/SGS/CE/BV |
9 | Application | Curves transition |
Safebuild is the source factory specializing in traffic guardrail with 25 years production and export experience. Due to our partnership with global brands, we understand the importance of your quality and you need more than a supplier. With Safebuild, the national leader in highway guardrails and Roller Barriers.
Convex & Concave Curved Guardrail Panels | |
Normal size of beam | L:2000/2300/3810/4000/4300/4320 Available in different sizes |
Size of post | As standard or customized |
Guardrail beam style | Convex, Concave Curved Guardrail |
Surface treatment | Hot dipped galvanized or plastic sprayed coating |
Guardrail standard | JT/T2811995/AASHTO M180/RAL RG620/AS NZS 3845-1999/EN1317 |
Steel grade | Q235,Q345,S235JR,S275JR,S355JR,EN10025,A283M. |
Full side galvanized | 550 (80µ) / 610 (85µ) / 1100 (160µ) / 1200 g/m2 (170µ) or as per your request |
Guardrail feature | Great corrosion resistant, high intensity, long and durable, with good impact resistance, low cost, long life, higher security, environmental protection, etc. |
Guardrail relevant parts | Post, Spacer (C,U,H,Z,Round, Square and Sigma types etc) and Fasteners, Bolts &Nuts,Terminal,Reflectors. |
MOQ | 1 meter |
Price item | EXW,FOB,CIF,CFR,etc |
Delivery | 10-25 working days |
We accept ODM producing as client's drawing. |
01 High quality steel materials
Safebuild use prime steel in each guardrail design.The advanced technology isuniform and smooth, without stripping rust,and the impact of collision has reached thetraffic sector standard.
02 Strong customization capability
With a R&D team of 12 people with more than 10 years experience, our factory provides from design, mold opening to production. So far, we have provided OEM and ODM services to more than 120 customers.
03 Strict quality control system
6 QC employees and 15 steps quality checking ensure our highway guardrail 100% reaching the standards of safety. Galvanized guardrail plate, not raised and cracking, the saline spray test does not have corrosion,the phenomenon of inflated and fall off without folds after high and low temperature, strong resistance to impact resistance.
04 Professional export services
We have more than 25 years of export experience in technology research and development, quality control, packaging and shipping and other links to provide professional advice and service.
01 Testing: For highway guardrail, it will be tested separately before leaving the factory to ensure that the dimensions and parameters meet the standards.
02 Certificate:As a professional manufacturer of highway guardrail , all of our products are with CE, ASTM, SGS, GSV, BSCI and ISO9001 Certificate and keeps updating regularly to ensure product quality and production safety.
